PI Weather Sensor: All of your racing weather station needs wrapped up into one sensor. The Weather Sensor has the capability of being custom programmed during manufacturing to provide you with your specifically selected desired channels. Built to order and ships complete with necessary wiring, hardware, and custom selected programming channel outputs.

Link to Weather Sensor Instructions

Our 0-5v Analog Sensors are compatible with most major ECU manufactures such as Holley™, Fuel Tech™, Haltech™, MoTec™, MaxxECU™, and many others!

Please specify which channel options you would like (4 MAX) - BE SURE TO INCLUDE UNITS.

Select 4 options from the following:

1. Temperature

F - Farenheit
C - Celcius
K - Kelvin
R - Rankine

2. Barometric Pressure (Baro)

inHg
KPa
mBar

3. Density Altitude (DA)

ft - feet
m - meters

4. Water Grains (WG)

GPP - Grains per Pound
GPKg - Grains Per Kilogram

5. Relative Humidity

% RH

6. Dew Point

F - Farenheit
C - Celcius
K - Kelvin
R - Rankin

7. Pressure Altitude

ft - feet
m - meters

8. Air Density

kg/m3 - kilograms per cubic meter
Slug/ft3 - slugs per cubic foot
Slug/in3 - slugs per cubic inch

9. Relative Air Density

10. Specific Enthaply

KJ/Kg - Kilojoules per Kilogram
BTU/Lbm - BTU per pound mass

11. Water Vapor Pressure

mBar

***YOU MAY SPECIFY A CUSTOM ANALOG OUTPUT VOLTAGE RANGE FOR FINER RESOLUTION. SENSORS CAPABLE OF 1.2 mV "STEPPED" RESOLUTION***

**PLEASE CALL IF YOU DESIRE CUSTOM OPTION NOT LISTED**

Weather Sensor - PRO SERIES, Custom Programming

Name: Weather Sensor - PRO SERIES, Custom Programming
Brand: Plimpton Innovations
SKU: PI-SENS-WS-CUSTOM
Price: 450 USD
Availability: InStock

$450.00

Channel Options

0/500

Optional Secondary Description field (optional)

0/500

Quantity

The PI PRO SERIES Weather Sensor is the first sensor of it's kind designed specifically for motorsports applications with unique features to revolutionize and improve any racing program.

If you have ever battled performance changes between days, tracks, or even from event schedule changes, this is just the sensor to integrate for maximizing consistency and performance. Eliminate all worry or dependency of cell phone reception to look up weather; your weather needs will now always be with you.

PI has integrated all of your racing weather station needs into independent electrical signals in one sensor. These signals can be fed into most aftermarket ECU's with the potential for logging, displaying weather on the dash, AND OR closed loop tuning changes. (We provide the sensor signal - the rest is up to YOU!)

These sensors can be programmed by PI to provide different outputs parameters or to use different units of measurement. (Example: exchange Temperature output with Relative Humidity). Please add Custom Weather Programming to the cart and choose your options!

UNDER THE HOOD OF THE PRO SERIES

This series contains a powerful CPU which takes in data from multiple onboard sensors, compiles it using sophisticated algorithms, and provides the user with cleanly compensated and useful data.

Designed and built in the USA!
5V Sensor Voltage Supply

0-5V Analog Weather Outputs

High Precision Sensing

Low Power Consumption

Small Footprint

Lightweight

Metal 10x32 threaded inserts for mounting dependability
IF THE FOLLOWING ARE WHAT YOU DESIRE, PLEASE SELECT THE STANDARD PROGRAMMING.

Temperature [F] (0 to 150F)

Barometric Pressure (Barometer) [inHg] (16 to 32inHg)

Density Altitude [ft] (-3000 to 12000ft)

Water Grains [GPP] (0 to 150GPP)
