PI 2-Axis G-meter: complete with necessary wiring and hardware. Compatable with
Link to G-Meter (Accelerometer) Instructions
Our 0-5v Analog Sensors are compatible with most major ECU manufactures such as Holley™, Fuel Tech™, Haltech™, MoTec™, MaxxECU™, and many others!
HOLLEY ECU USER NOTICE
Holley ECU Sensor Supply Voltage ("5V") varies from ECU to ECU. Actual measurements taken by Plimpton Innovations, LLC (using calibrated measuring equipment) have varied between "4.73V" to "4.89V". This does NOT impact sensor performance, however, calibrations may require slight modification. On average:
- "PIN LOW" values: subtract "0.02V" from values on card.
- "PIN HIGH" Values: subtract "0.09V" from values on card.
Holley User Example
"PIN 3 LOW" value on card = 1.24 V, Holley users should use 1.24V - 0.02V = 1.22 V.
"PIN 3 HIGH" value on card = 3.74 V, Holley users should use 3.74V - 0.09V = 3.65 V.
So the voltage values along the bottom row of the calibration table should read from 1.22V to 3.65V.
5G Dual Axis G-Meter (ACC-5XY Accelerometer)
- 5V Sensor Supply Voltage (NOT 12V Compatable)
- 0-5V Analog outputs (Longitudinal and Lateral G)
- High Precision Sensing
- Low Power Consumption
- Simple Mounting (Housing molded inserts)
- Compact electrical connection (terminals included)
- Common nominal sample frequency of 200Hz Bandwidth
The PI Dual-Axis (XY) 5G Accelerometer is designed specifically for motorsports. This unit features +/- 5g high sensativity in the X-axis and Y-axis directions. The X-axis data from the device is essential for making Acceleration and Deceleration power management decisions. The Y-axis data is essential for cornering and driving related tuning. Acceptable for vehicles of ALL power levels!
This device is the single most important sensor in all of motorsports!
Made in the USA!
